1. Product Brief Introduction

2. Technical Parameters

• Processor & Memory: 32-bit processor with 33MHz clock speed, 1MB RAM and 4MB flash memory.
• Interfaces: 4 serial ports (up to 115.2 kbps each) and 2 copper Ethernet ports (10/100 Mbps).
• Port Isolation: 500 VDC.
• Environmental Adaptability: Operating temperature range of -40 °C to 70 °C, IP67 protection level.
• Power Supply: 90-264 VAC input with redundant power design.
• Dimensions & Weight: 49 cm × 45.3 cm × 6.8 cm, 3.18 kg (net weight).

3. Key Functions

• Multi-protocol Support: Natively supports Tristation, Modbus (TCP/IP, RTU/ASCII), TCP/IP, SNTP, TSAA and other protocols for seamless integration with third-party devices.
• High Reliability: Adopts Triple Modular Redundancy (TMR) architecture, with three independent processors executing the same logic to ensure fault tolerance and 99.999% system availability.
• Data Exchange: Enables bidirectional high-speed data transmission between Tricon controllers, serial devices (sensors, frequency converters) and upper systems (PLC, DCS, SCADA).
• Fault Detection & Alarm: Built-in real-time self-diagnostic mechanism, triggering automatic alarms and recording Sequence of Events (SOE) with ≤40ms resolution when abnormalities occur.
• Online Replacement: Faulty modules can be replaced while the controller is online, ensuring continuous system operation.

4. Working Principle

The core principle of the TRICONEX 4351B is to realize protocol conversion and stable transmission of industrial signals. First, it receives RS-232/485 signals from on-site serial devices through its serial ports, which are quickly processed by the internal 32-bit processor. Then, the processed signals are converted into Ethernet signals (such as Modbus TCP/IP) and transmitted to upper systems. Meanwhile, it receives control commands from upper systems, converts them into serial signals and sends them to on-site devices, realizing bidirectional data interaction. The TMR architecture and redundant port design ensure that the module can automatically switch to standby ports when a single port or processor fails, and the electrical isolation technology blocks interference signals, thus guaranteeing the accuracy, real-time performance and continuity of data transmission.
